Viewing Subgroup Labels

Using this procedure, you will examine subgroup labels added to subgroups during data collection, which are only visible when viewing raw data or control chart data point details.

You can view subgroup labels in the following pages:

• Data Tables (from Finished Item tiles)

  1. In the work dashboard, locate the Finished Item tile.



  2. In the Finished Item tile, select the data collection entry.

  3. In the Data Table, examine the subgroup label added to the subgroup.



  For more information, please see Managing Data Tables.

• Data Tables (from Collected Data Pareto tiles)

  1. In the raw dashboard, locate the Collected Data Pareto tile.



  2. In the Collected Data Pareto tile, select the number in the Count column for the desired data collection category (Automatic, Checklist, Manual).



  3. In the Collections table, select the timestamp in the Time column for the desired subgroup.



  4. In the Data Table, examine the subgroup label added to the subgroup.



  For more information, please see Managing Data Tables.

• Raw Data Downloads (from Raw Dashboards)

  1. In the raw dashboard, select Download Raw Data .
  2. In the Download dialog box, select Save, and in the Save As dialog box, browse to the desired save location on the computer (for example, the Windows Downloads folder).
  3. In Microsoft Excel, open the saved file and examine the subgroup labels in the downloaded data.

  For more information, please see Downloading Raw Data.

• Plot Point Details (from Control Chart)

  1. In the Control Chart, select the plot point for the desired subgroup.



  2. If the Plot Point Details panel does not display Subgroup Label, select Entities, select to check the Subgroup Label checkbox, and then select Done.
  3. In the Plot Point Details panel, examine the subgroup label added to the subgroup.

  For more information, please see Viewing Plot Point Details in Managing Control Charts.

• Data View Columns (from Control Chart Data View)

  1. In the Control Chart, select More and then select Data View .



  2. If the Data View chart does not display the Subgroup Label column, select Configure Columns , select to check the Subgroup Label checkbox, and then select Done.
  3. In the Data View chart, examine the subgroup label added to the subgroups.

  For more information, please see Configuring Data View Columns in Managing Data View Charts.
